3.2V 20ah LiFe PO4 Battery Pack
- Model
- 3.2V 20ah
Item specifics
- Battery voltage
- 3.2V
- Battery capacity
- 20ah
- Battery type
- lifepo4 battery pack
- Single cell
- 26650
Review
Description
3.2V 20ah LiFe PO4 Battery Pack
All of the below information are correct and REAL. | |
Product name | Lithium iron phosphate battery pack |
Style name | LiFe PO4 battery 3.2V20Ah |
Norminal Capacity | 20Ah |
Nominal Voltage | 3.2V |
Max charge voltage | 3.65V |
Cut-off discharge voltage | 2.5V |
Max continuous discharge current | 1-2A |
Charge current | 1-2A |
Output power | 64W |
Working time | Output 3.2V 2A(6.4w): approx 10hours |
Output 3.2V 3A(9.6w):approx 7hours | |
Charge port(IN) | wire leads or selected plug |
Discharge port(OUT) | |
PVC color | Blue |
Battery dimension(mm) | 208x70x26 |
Weight | App.490g |
Battery cell Brand | Chinese Brand cell |
Battery cell certification | CB,CE,UL,UN38.3,BIS,KC,MSDS,ROHS,CQC,SGS,EMC |
Battery protection | Over charge&discharge, over current, short circuit |
Cycle life | standard charge&discharge capacity ≥80% C5mAh ,cycle life ≥1000 |
Application | Lighting, Garden sprayer, outdoor instrument, door control, Solar LED,12v lead acid battery replacement etc. |
Package | 18pcs in a carton(15x29x37cm), about 8.6kgs/carton |
Warranty | 12months |
